Plate heat treatment equipment

Inquire Now Next Product

Product Details

Main technical parameters of the sheet heat treatment production line:

Applicable workpieces: Suitable for medium frequency heat treatment of slab, steel plate, cutting edge plate, engineering blade plate, etc.

Power supply system: quenching 200-800KW/2.5-4.0KHZ, tempering 160-500KW/1.0-2.5KHZ, hourly output 0.6-2.5 tons.

·Scope of application: 20mm-60mm thick, 80mm-500mm wide.

Feeding system: roller conveyor+power double pinch roller, each axis is driven by an independent motor reducer and controlled by an independent frequency converter; Flexible design of differential output, segmented control of operating speed. Roller electrical isolation: In response to the problem of workpiece and roller ignition, we have designed a sturdy and durable roller electrical isolation system to solve the problem of workpiece ignition damage. ·Formula management function: A powerful formula management system that automatically calls relevant parameters after selecting the steel grade and plate type parameters to be produced, eliminating the need to manually record, view, or input parameter values required for various workpieces

Energy conversion: using quenching+tempering method, with a power consumption of 380-400 kWh per ton.

Plate heat treatment equipment

Advantages and characteristics

Advantages and characteristics of sheet heat treatment production line:

Good straightness

Adopting the Forever sheet induction heating and heat treatment production line, the straightening function is designed during the heat treatment process, and the sheet can achieve good straightness after heat treatment; Uniform heating temperature, high temperature control accuracy, small temperature difference, and no pollution

The Yuantuo series variable frequency power supply is easy to directly and accurately detect changes in load current, thereby achieving closed-loop control of output power. The product has high precision in heating temperature control and small temperature difference between the core and the surface. There will be no harmful gases, smoke, or other environmental pollutants during the production process.

·High degree of mechanization and automation

The high degree of intelligence in power supply, temperature adjustment, frequency conversion automatic tracking, variable load adaptive, power automatic adjustment and other intelligent advantages enable "one click" operation, truly realizing automated and intelligent induction heating.

·Temperature closed-loop, intelligent, PLC overall operation control system

Infrared thermometer measures the heating temperature of the billet at the outlet of the induction heating furnace, monitoring for overheating or incomplete heating. To control the temperature of the sheet metal within the target range. Reduced the generation of non-conforming products and ensured consistency in product quality.
