Carbon steel bar quench and temper induction equipment

Forever has senior engineers who have worked in the field of induction heating for many years. They have rich experience and practice in the design, process, manufacturing, and management of carbon steel rod quenching and tempering induction furnaces. We focus on providing customers with excellent solutions and services for carbon steel rod quenching and tempering induction furnaces and steel pipe heating equipment. Our medium frequency induction heating furnaces are sold to multiple countries, where you can enjoy our reliable service, stable and reliable product quality, and convenient transportation location! Welcome to visit the factory and negotiate business!

The core advantages of carbon steel rod induction hardening and tempering furnace are efficient heating, precise temperature control, and automated production, especially suitable for batch processing of workpieces with high hardness and wear resistance requirements.

specific characteristics are as follows:

1、 Heating and temperature control

Electromagnetic induction heating: Directly heating steel bars through a magnetic field, with an efficiency 2-3 times higher than that of a resistance furnace, and a power consumption of ≤ 500 degrees per ton.

Multi point temperature control monitoring: Real time feedback of surface and core temperature, temperature difference controlled within ± 5 ℃, ensuring uniform hardening layer.

Adjustable parameters: Power supply, mechanical parameters, and cooling speed can all be precisely controlled through a computer system.

2、 Process and Performance

Quenching and cooling: After heating to 850-920 ℃, spray cooling is carried out, and the cooling water flow rate is adjusted in sections. The depth of the hardened layer is 2-6mm.

Tempering process: eliminates quenching stress, adjusts toughness, increases carbide dispersion in microstructure, and has high wear resistance.

Mechanical properties: High surface hardness, improved fatigue strength, and enhanced impact resistance.

3、 Automation and Efficiency

Full process automation: integrating loading, heating, quenching, tempering, and unloading to reduce manual intervention.

Fast production pace: The heating speed can reach several hundred to several thousand degrees per second, far higher than traditional heat treatment furnaces.

Strong adaptability: The conveying method and line speed can be adjusted according to different specifications of raw materials and process requirements.

4、 Application scenarios

Large scale production: suitable for assembly line operations, with consistent clamping and positioning, and production pace matched with induction hardening.

High precision requirements: raw material processing for parts such as cutting tools and molds.
