The core advantages of Forever Intelligent induction heating power supply lie in high efficiency and energy saving, precise control, stability and reliability, and intelligent operation.
1. Efficient and energy-saving design
High power factor (≥ 0.95): Adopting IGBT inverter technology, compared with traditional thyristor power supply, the energy conversion efficiency is improved by 20%~30%, effectively reducing useless power loss.
Adaptive load matching: automatically adjusts frequency (1-10kHz) and power output to avoid the phenomenon of “big horse pulling small car”, reducing no-load losses by more than 50%.
Energy feedback system (optional): When the load suddenly changes, the excess energy is fed back to the grid, further saving 5% to 8% energy.
2. Precise control and stability
Digital PID regulation: current and voltage control accuracy reaches ± 1%, frequency fluctuation ≤ 0.1%, ensuring heating uniformity (such as gear quenching hardness deviation ≤ HRC2).
Quick response capability: Dynamic response time<10ms, suitable for automated production lines with high-frequency start stop operations (such as forging robotic arm linkage operations).
Multiple protection mechanisms: full protection against overcurrent, overvoltage, phase loss, overheating, etc., fault self diagnosis and real-time alarm, equipment lifespan extended by 30%.
3. Intelligent control system IGBT medium frequency power supply
Touchscreen Human Machine Interface (HMI): Real time display of power, frequency, and temperature curves, supporting formula storage (≥ 100 sets of process parameters).
Remote monitoring and data export: Connected to MES system via RS485/Ethernet to achieve energy consumption statistics and fault record analysis.
