Continuous casting billet heating furnace
Features:
| Billet size | 130*130mm |
| Billet length | 8000mm |
| Billet surface Temp.: | 700-800 ℃ |
| Increasing Temp. to | 1100-1200 ℃ |
Product Detail
Application Video
Product Tags
18 years experience,excellent continuous casting billet heating furnace, intelligent series resonant induction heating power control, which makes our billet heating furnace energy saving 10% -30% and more reliable. So far, forever continuous casting billet heating furnace has got very good feedback from Taiwan and Vietnam customers.
Technical parameters for Continuous casting billet heating furnace
| Product name | Continuous casting billet heating furnace |
| Brand | Forever |
| Billet size | 130*130mm |
| Billet length | 8000mm |
| Temperature before charging induction heater: | 700-800 ℃ |
| Temperature after induction billet heater: | 1100-1200 ℃ |
| Capacity | 60 ton/h |
Supply scope for Continuous casting billet heating furnace
| No. | Machine name | Specification | Quantity |
| 1 | Medium frequency power supply device | KGPS4000KW | 1 Set |
| 2 | Medium frequency capacitor cabinet | 1 Set | |
| 3 | Induction billet heater | 130*130*1600 mm | 1 Sets |
| 4 | Connection cable | 500mm2X5m | 4 Pieces |
| 5 | Remote control console | Power supply start, stop, temperature display ; closed loop control, PLC touch screen for automatic control, | 1 Set |
| 6 | Infrared thermometer(High temperature type) | 2 Sets | |
| 7 | Inverter cabinet | 1 Set | |
| 8 | Frequency reducer | 2 Sets |
Advantages of Forever Continuous casting billet heating furnace
1.Continuous casting billet heating furnace has a series resonant power control, full digital, rectifier fully open, high power factor, no harmonic pollution.
2.Uniform heating, less oxidation and decarbonization, low power consumption.
3.PLC automatic control for the whole heating process, display & record all the process parameters during heating process.
4.The induction heating coil i adopts T2 oxygen-free copper tube winding with more than 3mm wall thickness.
5, The carrier rollers between induction heaters is made of 304 non-magnetic stainless steel.
Specialist of billet heating furnace and system in China; Glad to be your business partner in induction heating field.
