Sucker Rod Heat Treatment Equipment

Sucker Rod  Heat Treatment Equipment


1.Induction heating power: DSP+IGBT ,Intelligent induction heating power,saving energy 10%-15% ,no pollution.

2.Process monitoring screen and Data logging and Archiving

3.Application:Heat Treatment for many kinds of metal parts,no matter the part size.

Product Detail

Application Video

Product Tags

Sucker Rod  Heat Treatment Equipment for sucker rod hardening & tempering

induction heat treatment equipment usually means that the solid metal materials through the heating,heat preservation and cooling to change the chemical composition and the organization of the surface or  the inter of the metal materials to obtain the required  properties. It is a metal hot working process.

Simple introduction of the sucker rod heat treatment equipment :

Sucker rod heat treatment equipment working location:  horizontal placement  and parallel distribution of the double station quenching.

The length range of the sucker rod for heat treatment : 7000mm-9000mm (we can design and manufacture the equipment according to the customer’s requirement)

The diameter of the sucker rod for heat treatment: diameter 19.05mm,diameter 22.2mm,diameter 25.4mm

Total power of the Sucker rod heat treatment equipment: 7500kw

Frequency of the medium frequency power supply:1~2.5KHZ

Production capacity :15-25 pieces/hour   (one  station)

                               30-50 pieces/hour  (two  stations)coucustomer visting

Forever company producing different models induction heating equipment and induction heat treatment for all kinds of metals.Please feel free to contact with us.

Overseas manager: Tom Wang

Phone: 0086-13303078975(whatsapp, wechat,line)

Specialist of  inductoin heat treatment furnace in China; Glad to be your business partner in induction heating field.
